Qualified 6 Inch DTH Hammer For Mining And Water Well Drilling With QL60 DHD360 SD6 Shank Type

Name: Qualified 6 Inch DTH Hammer For Mining And Water Well Drilling With QL60 DHD360 SD6 Shank Type
Brand: teamwhole
Price: 1 USD

Brand Name : teamwhole

Model Number : TH139,DHD360,QL60,SD6,MACH60

Certification : ISO9001

Place of Origin : Hunan, China (Mainland)

MOQ : 1 Piece/Pieces dth hammer (Min. Order)

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 6000 Piece/Pieces per Month dth hammer

Delivery Time : Shipped in 20 days after payment

Packaging Details : All the dth hammer are packed by Inner package with cartons,outer package with wooden cases

Machine Type : Drilling Equipment

Material : Alloy Steel

Processing Type : Forging

Use : Ore Mining, Ore mining

Packing : Carton and Wooden case

Contact Now

Qualified 6 Inch DTH Hammer For Mining And Water Well Drilling With QL60 DHD360 SD6 Shank Type

Product Application

Teamwhole down the hole(DTH)hammers have proven superior performance and adaptability to different application.
DTH hammers are ranges six main series from 3.5" to 24",it serves to drilling projects in mining,water well,geothermal,
foundation,oil and gas.
Choosing the right hammer is largely determined by hole size and rock formation.We design our hammers with different outstanding advantages,and provide the various shanks for international use.
We are the only manufacturer to offer the optimum performance and the competitive price in every single application.
It's all right here. At Teamwhole drilling tools and Machinery.

DHD SHANK HAMMER

Model	Product code	Thread connection	Outer diameter	Rec.hole size (mm)	Shank style	Length without bit(mm)	Weight without bit(kg)	Working pressure (bar)
3.5"	223000	API2 3/8"reg pin	80	90-115	DHD3.5	990	28	14-24
4"	230000	API2 3/8"reg pin	98	110-138	DHD340	1045	38	14-24
5"	240000	API3 1/2"reg pin	126	138-165	DHD350	1214	85	14-24
6"	252000	API3 1/2"reg pin	142	152-203	DHD360	1300	98	14-24
8"	260000	API3 1/2"reg pin	180	203-271	DHD380	1522	190	16-22
12"	282000	API6 5/8"reg pin	274	331-445	DHD112	1938	675	14-20

Qualified 6 Inch DTH Hammer For Mining And Water Well Drilling With QL60 DHD360 SD6 Shank Type

Main Features

1) Reliability

The piston of DTH Hammer uses the special (imported) high nickel alloy steel, with advanced heat treatment as military industry standard.
Strengthening processing on hammer surface for higher were-resistance.

2) Suitability

Specially designed drill bits for middle soft and hard rock formations. Easily disassembly thread for easy maintenance.

3) Efficiency

Extra-short structure design DTH hammer and bit for great efficiency of high impact energy transmission, with high impact power and fast drilling rate.
Hammer and bit design are optimized by computer simulation, with best air distribution chamber and air tightness design.

Certifications

Packing & Delivery

Our Service

1. Teamwhole offers the market most comprehensive range of DTH hammers. There are hammer solutions for water well drillers, miners and quarry drillers as well as for contractors in construction, oil and gas. Teamwhole's DTH hammers are available in holes sizes from 3.5 to 48 inches in diameter.

2. Teamwhole's flexible and stable ODEX system wins great reputation in users. Reliable quality,innovative design and professional service ensure the fulfill of many projects.

3. We even offer reverse circulating RC hammers for exploration. We are the earliest in China for RC since 2004. Now the RC hammer and bits are delivered to Australia,South Africa,Russia and Mongolia in large scales.

More than 30 experts supports the technology and enhance the development.
Offer the guide service for assembly and problem-analyse service during using.
